MX2000N: Diamond Antenna Triplexers
Request a quote for latest pricing
- Dimensions: 86Wx25Hx64Dmm
- Weight: 360g
- Pass Band Frequency: LPF/1.6 to 60MHz, BPF/110 to 170MHz, HPF/300 to 950MHz
- Power: 1.6-60MHz 800W (PEP), 110-170MHz 800W (PEP), 300-950MHz 500W (PEP)
- Insertion Loss: 1.6-60MHz Less than 0.15dB, 110-170MHz Less than 0.2dB, 300-950MHz Less than 0.25dB
- Isolation: More than 60dB (In amateur band)
- Impedance: 50 ohms
- VSWR: Less than 1.2 (In amateur band)
- Connector: MIX SO-239, 50MHz PL-259, 144MHz PL-259, 430MHz NP
- Coaxial cable: 5D-2VS (35cm)
