- Physical Dimensions: 9.3” x 5.5” x 2.3” (23.5 x 14.0 x 5.8 cm)
- Display Resolution: 800 x 480 pixels
- Display Type: WVGA color
- Weight: 1.7 lbs (0.8 kg)
- Water Rating: IPX7
- Transmit Power: 500 W (RMS)
- Sonar Features & Specifications:
- Dual-frequency (50/200 kHz) sonar capable: Yes
- Dual-beam (77/200 kHz) sonar capable: Yes
- Frequencies Supported: Traditional: 50/77/200 kHz; CHIRP (mid and high); ClearVü 260/455/800 kHz
- Bottom lock (shows return from the bottom up): Yes
- Water temperature log and graph: Yes
- Fishfinder Features:
- Split-screen zoom: Yes
- UltraScroll® (displays fish targets at higher boat speeds): Yes
- Fish Symbol ID (helps identify fish targets): Yes
- AutoGain Technology (minimizes clutter, maximizes targets): Yes
- Adjustable depth line (measures depth of underwater objects): Yes
- A-Scope (real-time display of fish passing through transducer beam): Yes
- Water temperature sensor included: Yes
- Additional:
- One 4-pin transducer port
- Quickdraw Contours
- Integrated GPS
- Mark Waypoints
- Course over Ground (COG)
- Current draw @ 12V: 0.55A
